Information
It is a high-end lamp that provides key lighting for public cultural building space collection lighting and commercial spaces such as hotels, bars, restaurants and clubs. Developed in cooperation with well-known lighting designers in other countries, it is a consistent choice for designers and architects who pursue lighting.
9-16 watts, simple and small structure and appearance design, used in a low space of 3-5 meters, can be perfectly integrated into various spaces and ceiling structures. The light outlet angle is 9-50 degrees, and different angles can be selected according to different spaces and collections. Equipped with a variety of optical accessories and lenses, it can be used almost everywhere, regardless of the size and distance of the object, and the space.
Unique lighting experience
It can change dozens of beam angle types, and optical accessories are available at 5 different beam angles. Equipped with soft light, diffusion filter. With different focusing angles, it can produce countless lighting art effects such as soft and uniform, stretching, wall washing, light interception and projection.
Excellent color rendering and saturation
For most cultural architectural space and space applications, the quality of color presentation is crucial.Used with luminus LED light source ,The CRI is 97,The R9 is 96,the CQS value is 94,and the TM30 value is 94.1. It not only provides high CRI, but also improves color saturation. This makes the colors of paintings, collections, meals, clothing or any other object more vivid than ever.
Multiple control methods
Compatible with DALI, 0-10V dmming, wireless Bluetooth, Casambi, 512DMX and other control methods, it can give designers a variety of control options to reduce emissions and save energy, protect the illuminance of collections and sustainable development
>
Specifications
| Product series | XingNuo |
|---|---|
| Model | 8663 |
| Power | 16W |
| LED color (CCT) | 3000K/3500K/4000K/5000K |
| Optional Ra | Ra>90 or Ra>95 |
| SDCM | SDCM<3 |
| Whole light flux | 622lm-721lm |
| Power factor | >0.9 |
| Zoom angle | 9°-50° |
| Illuminance parameters | 9°at 9.84 ft(3 meters)Center illuminance >2000LX |
| Optional stretch lens | 30°×10° or 15°×5° |
| Wall washing lens | 60°×15° |
| Cut-off lens | Cut-off or Project logo |
| Optional dimming | 0-10V/DALI/ Casambi/DMX512 |
| Optional installation | Three/Four-track or Ceiling |
| color | White or Black or Customized colors |
| lifetime | 50000h |
